Product details
|
Model
|
GWT 150-5
|
|
Power
|
150w
|
|
Maximum power
|
180w
|
|
Number of blades
|
5
|
|
Blade material
|
stainless steel or reinforced fiberglass
|
|
Wind wheel diameter
|
1.2m
|
|
Wind wheel height
|
1m
|
|
Starting wind speed
|
0.8m/s
|
|
Cut-in wind speed
|
2.5m/s
|
|
Rated wind speed
|
10m/s
|
|
Cut-out wind speed
|
17m/s
|
|
Safe wind speed
|
30m/s
|
|
Generator
|
three-phase permanent disk generator
|
|
Voltage
|
24V
|
|
Protection grade
|
IP67
|
|
Tower pole height
|
5-8 meters
|
|
Controller
|
intelligent controller
|
|
Working temperature
|
- 40 ℃ - 80 ℃
|
|
Design life
|
20 years
|
Installation tips for wind turbines generator
A wind turbine is a promising source of renewable energy. However, installing them can be a complicated process. Here are a few tips to help ensure successful installation of a wind turbine.
1. Site selection:
The ideal location for a wind turbine is an open area with constant wind flow. It is important to take into account factors such as surrounding terrain, proximity to overhead power lines, and zoning regulations. Consult with an expert to determine the best location for your wind turbine.
2. Foundation:
The foundation is a crucial component of the wind turbine. A strong foundation will ensure that your wind turbine is stable and secure. The type of foundation required will depend on the location and size of the turbine. Consult with a professional to ensure the proper foundation is installed.
3. Tower installation:
Wind turbine towers need to be installed upright and secured to the foundation. The installation of the tower should be done carefully to ensure stability and safety. Always follow the manufacturer’s instructions and consult with an expert for guidance.
4. Wiring:
Wiring the turbine to the grid is an important step. This should be done by a licensed professional and in compliance with local regulations and safety codes. Proper wiring will ensure that the electricity generated by the turbine is safely transferred to the grid.
5. Maintenance:
Maintenance of the wind turbine is essential to ensure its optimal performance. Regular inspections and cleaning of the blades, hub, and tower are crucial. Consult with the manufacturer for specific maintenance instructions and schedule routine maintenance visits with a professional.
In summary, installing a wind turbine can be complex and requires specialized knowledge and expertise.
